24 SEBU8121
Operation Section
Features and Controls
i02259829
Sensors and Electrical
Components
Sensor Locations for the 1104
Engine
g00894185
Illustration 1 5
Left side v iew of the 1104 engine
Typical example of a 110 4 engine
(1) Electronic c ontrol module (ECM)
(2) Intake manifold temperature sen sor
(3) Intake manifold pressure sensor
(4) Speed/timing sensor
(5) Engine oil pressure sensor
(6) Machine interface connector
g00915
275
Illustration 16
(7) Typical location of the v oltage load protection module by the
ECM
