SEBU8121 39
Maintenance Section
Refill Capacities
Maintenance Section
Refill Capacities
i02249844
Refill Capacities
Lubrication System
The refill capacities for the engine crankcase
reflect the approximate capacity of the crankcase
or sump plus standard oil filters. Auxiliary oil filter
systems will require additional oil. Refer to the OEM
specifications for the capacity of the auxiliary oil filter.
Refer to the Operation and Maintenance Manual,
“Maintenance Section” for more information on
Lubricant Specifications.
1104 Engine
Table 2
1104 Engine
Compartment or System
Liters
Quarts
Standard O
il Sump for the Engine
Crankcase
(1)
6.5
7
(1)
These values are the approximate capacities for the crankcase
oil sump which include the standard factory installed oil filters
and a standard crankcase oil sum p. Engines with auxiliary oil
filters will require a dditional oil. Refer to the OEM specifications
for the capacity of the auxiliary oil filter.
Cooling S ystem
To maintain the cooling system, the Total Cooling
System capacity must be known. The approximate
capacity for the engine cooling system is listed
below. External System capacities will vary among
applications. Refer to the OEM specifications for the
External System capacity. This capacity information
will be needed in order to determine the amount
of coolant/antifreeze that is required for the Total
Cooling System.
1104 Engine
Table 3
1104 Naturally Aspirated Engine
Compartment or System Liters Quarts
Engine Only 10.4 11
External cooling system capacity
(OEM recomme
ndation)
(1)
Total Cooling System
(2)
(1)
The external cooling sy stem includes a radiator or an
expansion tank with the following compo nents: heat exchanger,
aftercooler, and piping. R efer to the OEM specifications. Enter
the value for the external system capacity in this row.
(2)
The Total Cooling System includes the capacity for the engine
cooling system plus the capacity for the external cooling
system. Enter the total in this row.
Table 4
1104 Turbocharged Engine
Compartment or System Liters Quarts
Engine Only 11.4 12
External cooling System capacity
(OEM recommendation)
(1)
Total Cooling System
(2)
(1)
The external cooling sy stem includes a radiator or an
expansion tank with the following compo nents: heat exchanger,
aftercooler, and piping. R efer to the OEM specifications. Enter
the value for the external cooling system capacity in this row.
(2)
The Total Cooling System includes the capacity for the engine
cooling system plus the capacity for the external cooling
system. Enter the total in this row.
i02280119
Fluid Recommendations
General Lubricant Informa tion
Because of government regulations regarding the
certification of exhaust emissions from the engine,
the lubricant recommendations must be followed.
Engine Manufacturers Association (EMA)
Oils
The “Engine Manufacturers Association
Recommended Guideline on Diesel Engine Oil” is
recognized by Perkins. For detailed information
about this guideline, see the latest edition of EMA
publication, “EM A DHD -1”.
