Engine Oil Level - Check
Hot oil and hot components can cause personal
injury. Do not allow hot oil or hot components to
contact the skin.
Illustration 57 g06241718
Oil level gauge and oil filler
(1) Oil filler cap (2) Oil level gauge
Illustration 58 g00110310
Partial view of the oil level gauge
(Y) “ADD” mark
(X) “FULL” mark
NOTICE
Perform this maintenance with the engine stopped.
92
SEBU9074-06
Maintenance Section
Engine Oil Level - Check
