Product Information
Section
General Information
i06731991
Model View Illustrations
The following model views show typical features of
the engine. Due to individual applications, your
engine may appear different from the illustrations.
2806C
Illustration 13 g06095280
Typical example
(1) Front lifting eye
(2) Breather outlet hose
(3) Rear lifting eye
(4) Air cleaner
(5) Electronic control module
(6) Starting motor
(7) Secondary fuel filter
(8) Primary fuel filter
(9) Fuel transfer pump
(10) Fuel priming pump
(11) Air intake from air charge cooler
16
SEBU9074-01
Product Information Section
General Information
