Protection equipment
Before resetting protection equipment, it must be established whether special settings (for that individual
engine) have been specified in the engine sales contract. This is particularly important with ALL high water
temperature settings, and ALL Cogen applications.
Standard settings for protection equipment are specified below.
Caution: The above standard settings do not supersede any settings specified in the engine sales contract.
Electrical system
Shutdown switches Alarm Shutdown
High oil temperature 100 °C 105 °C
Low oil pressure 2,06 bar (30 lb/in
2
) 1,93 bar (28 lb/in
2
)
High water temperature
71 °C Thermostat 91 °C 96 °C
85 °C Thermostat 96 °C 101 °C
96 °C Thermostat 100 °C 105 °C
Overspeed
15% above max. running speed
(Except 1800 r/min which is 7%)
Engine model 4012 4016
Voltage 24V
Alternator Belt driven
Alternator output 30A
Starter motor Twin Prestolite
No. of teeth (gear ring) 156
No. of teeth (starter motor) 12
Battery (lead acid) 24V DC (2 x 12V)
Battery capacity down to 0 °C (32 °F) 286 Ah
