Perkins 4012 - Engine Views; 12 Cylinder Engines; ‘B’ Bank (Gearcase End); ‘A’ Bank (Flywheel End)

User’s Handbook, TSL 4186E, Issue 2 19
2
4012/16 Diesel
Engine views 2
Introduction
Perkins engines are built for specific applications and the views which follow do not necessarily match your
engine specification.
12 cylinder engines
‘B’ Bank (gearcase end)
‘A’ Bank (flywheel end)
