User’s Handbook, TSL 4186E, Issue 2 51
4012/16 Diesel
Preparation for equalising bridge pieces and setting valve clearances
Special requirements
1 Take out the screws (A1) and remove all of the engine rocker covers (A2).
2 Fit the engine cranking device (B1) to a starter mounting in the flywheel housing (B2).
3 Using a socket and ratchet wrench press against the spring loaded bolt head (B3) until the pinion engages
with the flywheel gear.
4 Crank the engine to the desired position, using flywheel markings viewed through the inspection hole in the
flywheel housing (C1). Refer to "Bridge piece and valve clearance setting sequence" on page 52.
Note: To get an accurate reading line up by eye the tip of both pointers with the marks on the flywheel (C2).
Special tools
Description Part number
Engine cranking device SE253
