Perkins 854F-E34T - Page 27

(Table 4, contd)
J1939 Code
Description
Refer to Procedure
2970-2
Accelerator Pedal 2 Low Idle Switch : Erratic, Intermittent, or
Incorrect
Idle Validation - Test
3217-3
Aftertreatment #1 Intake O2 : Voltage Above Normal Oxygen Level - Test
3217-4
Aftertreatment #1 Intake O2 : Voltage Below Normal Oxygen Level - Test
3217-5 Aftertreatment #1 Intake O2 : Current Below Normal
Oxygen Level - Test
3217-6 Aftertreatment #1 Intake O2 : Current Above Normal
Oxygen Level - Test
3217-12 Aftertreatment #1 Intake O2 : Failure
Oxygen Level - Test
3217-13 Aftertreatment #1 Intake O2 : Out of Calibration
Oxygen Level - Test
3217-15
Aftertreatment #1 Intake O2 : High - least severe (1) Oxygen Level - Test
3219-15
Aftertreatment #1 Intake Gas Sensor at Temperature : High -
least severe (1)
Oxygen Level - Test
3219-17
Aftertreatment #1 Intake Gas Sensor at Temperature : Low -
least severe (1)
Oxygen Level - Test
3222-3
Aftertreatment #1 Intake Gas Sensor Heater : Voltage Above
Normal
Oxygen Level - Test
3222-4
Aftertreatment #1 Intake Gas Sensor Heater : Voltage Below
Normal
Oxygen Level - Test
3222-5
Aftertreatment #1 Intake Gas Sensor Heater : Current Below
Normal
Oxygen Level - Test
3242-0
Particulate Trap Intake Gas Temperature : High - most severe
(3)
Sensor Signal (Analog, Passive) - Test
3242-3
Particulate Trap Intake Gas Temperature : Voltage Above
Normal
Sensor Signal (Analog, Passive) - Test
3242-4
Particulate Trap Intake Gas Temperature : Voltage Below
Normal
Sensor Signal (Analog, Passive) - Test
3251-0
Particulate Trap Differential Pressure : High - most severe (3)
Diesel Particulate Filter Collects Excessive Soot
3251-3
Particulate Trap Differential Pressure : Voltage Above Normal Sensor Signal (Analog, Active) - Test
3251-4
Particulate Trap Differential Pressure : Voltage Below Normal Sensor Signal (Analog, Active) - Test
3251-7
Particulate Trap Differential Pressure : Not Responding
Properly
Diesel Particulate Filter Has Differential Pressure Problem
3251-10
Particulate Trap Differential Pressure : Abnormal Rate of
Change
Diesel Particulate Filter Has Differential Pressure Problem
3251-16
Particulate Trap Differential Pressure : High - moderate severity
(2)
Diesel Particulate Filter Collects Excessive Soot
3251-17
Particulate Trap Differential Pressure : Low - least severe (1)
Diesel Particulate Filter Has Differential Pressure Problem
3251-18
Particulate Trap Differential Pressure : Low - moderate severity
(2)
Diesel Particulate Filter Has Differential Pressure Problem
3358-10
Engine Exhaust Gas Recirculation 1 Intake Pressure : Abnor-
mal Rate of Change
NRS Mass Flow Rate Problem
3509-2
Sensor Supply Voltage 1 : Erratic, Intermittent, or Incorrect Sensor Supply - Test
3510-2
Sensor Supply Voltage 2 : Erratic, Intermittent, or Incorrect Sensor Supply - Test
3511-2
Sensor Supply Voltage 3 : Erratic, Intermittent, or Incorrect Sensor Supply - Test
3697-5
Particulate Trap Lamp Command : Current Below Normal Indicator Lamp - Test
(continued)
UENR0612 27
Diagnostic Trouble Codes
