(Table 4, contd)
J1939 Code
Description
Refer to Procedure
3697-6
Particulate Trap Lamp Command : Current Above Normal Indicator Lamp - Test
3698-5
Exhaust System High Temperature Lamp Command : Current
Below Normal
Indicator Lamp - Test
3698-6
Exhaust System High Temperature Lamp Command : Current
Above Normal
Indicator Lamp - Test
3702-5
Diesel Particulate Filter Active Regeneration Inhibited Status :
Current Below Normal
Indicator Lamp - Test
3702-6
Diesel Particulate Filter Active Regeneration Inhibited Status :
Current Above Normal
Indicator Lamp - Test
3719-0
Aftertreatment 1 Diesel Particulate Filter Soot Load Percent :
High - most severe (3)
Diesel Particulate Filter Collects Excessive Soot
3719-16
Aftertreatment 1 Diesel Particulate Filter Soot Load Percent :
High - moderate severity (2)
Diesel Particulate Filter Collects Excessive Soot
4765-3
Aftertreatment #1 Diesel Oxidation Catalyst Intake Gas Temper-
ature : Voltage Above Normal
Sensor Signal (Analog, Passive) - Test
4765-4
Aftertreatment #1 Diesel Oxidation Catalyst Intake Gas Temper-
ature : Voltage Below Normal
Sensor Signal (Analog, Passive) - Test
5055-17
Engine Oil Viscosity : Low - least severe (1)
Oil Contains Fuel
5055-18
Engine Oil Viscosity : Low - moderate severity (2)
Oil Contains Fuel
5099-5
Engine Oil Pressure Low Lamp Data - Current Below Normal Indicator Lamp - Test
5099-6
Engine Oil Pressure Low Lamp Data - Current Above Normal Indicator Lamp - Test
5246-15
Aftertreatment SCR Operator Inducement Severity : High - least
severe (1)
See “Operator Inducement Codes”.
5246-16
Aftertreatment SCR Operator Inducement Severity : High - mod-
erate severity (2)
See “Operator Inducement Codes”.
5319-31
Aftertreatment 1 Diesel Particulate Filter Incomplete
Regeneration
Diesel Particulate Filter Active Regeneration Was
Interrupted
5324-7
Engine Glow Plug 1 : Not Responding Properly Glow Plug Starting Aid - Test
5325-7
Engine Glow Plug 2 : Not Responding Properly Glow Plug Starting Aid - Test
5326-7
Engine Glow Plug 3 : Not Responding Properly Glow Plug Starting Aid - Test
5327-7
Engine Glow Plug 4 : Not Responding Properly Glow Plug Starting Aid - Test
5357-31
Engine Fuel Injection Quantity Error for Multiple Cylinders ECM Memory - Test
5419-5
Engine Throttle Actuator #1 : Current Below Normal
Motorized Valve - Test
5419-6
Engine Throttle Actuator #1 : Current Above Normal
Motorized Valve - Test
5419-7
Engine Throttle Actuator #1 : Not Responding Properlyl
Motorized Valve - Test
5571-2
High Pressure Common Rail Fuel Pressure Relief Valve : Er-
ratic, Intermittent, or Incorrect
Fuel Rail Pressure Problem
5571-7
High Pressure Common Rail Fuel Pressure Relief Valve : Not
Responding Properly
Fuel Rail Pressure Problem
5571-10
High Pressure Common Rail Fuel Pressure Relief Valve : Ab-
normal Rate of Change
Fuel Rail Pressure Problem
5571-14
High Pressure Common Rail Fuel Pressure Relief Valve : Spe-
cial Instruction
Fuel Rail Pressure Problem
(continued)
28 UENR0612
Diagnostic Trouble Codes
