How to renew the element of the fuel lter
Warning! Discard the used canister and fuel oil in a safe place and in accordance with local regulations.
Caution: It is important that only the genuine Perkins parts are used. The use of wrong parts could damage
the fuel injection equipment.
1. Thoroughly clean the outside surfaces of the fuel lter assembly (J1).
2. Loosen the drain device (J2) at the bottom of the lter canister and drain the fuel into a suitable
container.
3. Turn the clamping ring (J3) to the left to free the lter.
4. Ensure that the inside of the lter head is clean
5. Ensure the locating nodes (J4) are in the correct position to slot into the lter head.
6. Turn the clamping ring to the right to lock in position.
7. Eliminate the air from the fuel lter.
Fuel pre-lter
This will normally be tted between the fuel tank and the engine. Check the lter bowl for water at regular
intervals and drain as necessary.
Caution: Do not run the electric fuel lift pump for more than 60 seconds without fuel. The fuel pump can be
permanently damaged as it relies on the fuel for lubrication.
