M1
Settings and adjustments
Figure 48. Adjusting armrest pad position.
Armrest pad position is adjustable for optimal comfort.
1. Loosen the four screws (A) under the armrest.
2. Slide the armrest pad to the required position.
3. Tighten the screws (A) using a torque wrench. Tightening
torque: 7.23 lb.ft.
Armrest Corpus
Armrest height
The following items are necessary for this task:
• Torque wrench.
• Allen key socket, 6 mm.
87
