M1
Settings and adjustments
Swing away leg rest length
The following items are necessary for this task:
• Torque wrench.
• Allen key socket, 5 mm.
Figure 57. Swing away leg rest length adjustment.
1. Release the lower part of the leg rest by loosening the screws
(A).
2. Adjust the leg rest length to desired position.
3. Tighten the screws (A). Tightening torque: 5.5 lb.ft.
96
