Cab, Instruments and Controls
43
E. REV COUNTER
Green area: economical
White: less economical
Blue area: only permitted when driving downhill and for optimal use of the engine
brake
Red area: not permitted
F. TRIP METER RESET BUTTON
The trip meter is set to zero with the reset button.
G. ODOMETER AND TRIP METER
The total distance is displayed in "km" or "mls" in the top section of the display.
H. WARNING INDICATORS
See section concerned.
I. DIESEL EXHAUST FLUID GAUGE
The Diesel Emission Fluid gauge indicates the total (approximate) amount of DEF in
the tank. In addition to indicating empty and full, the gauge also indicates the DEF
level in graduated increments. When the DEF level in the tank reaches 10% full, a
red warning light in the gauge illuminates. When the DEF level in the tank reaches
5%, Refer to your PACCAR Engine After-Treatment Control Operator's Manual for
more information.
