Pfaff 1051

Adjustment
11 - 6
11.05.04 Neutral position of the needle feed (only on PFAFF 1051 and 1181)
Requirement
At stitch length setting “ 0” the needle bar must not make any feeding motion when the
balance wheel is turned.
Fig. 11 - 05
● Set stitch length “ 0” .
● Turn crank 1 (screw 2) according to Requirement.
1
2
