Adjustment
12 - 34
12
.06.02
Knife height
Requirement
When the adjustment lever
1
is set at "0" and the knife is at the top of its stroke, the top
edges of the needle plate and knife should be at the same level.
●
Set adjustment lever
1
at "0".
●
Remove cover cap
2
and turn the motor impeller wheel until the knife is positioned at its
t.d.c.
●
Adjust linkage rod
3
(screw
4
) in accordance with the requirement.
Fig. 12 - 33
2
3
1
4
75
77
