Pfaff 918

Adjustment
10
0
1
2
6
5
3
4
Fig. 1 - 05
1.05.04 Locking lever
Requirement
The zigzag stitch adjustment lever 3 must be able to be locked in any position.
● Loosen screw 2.
● Press locking lever 1 against the zigzag stitch adjustment lever 3.
● Turn pivot pin 4 as far as possible to the left.
● Release locking lever 1.
● Locking lever 1 must be parallel to the zigzag stitch adjustment lever 3.
● Tighten screw 2.
1
3
2
4
