Adjustment
21
Fig. 1 - 15
1.05.15 Zeroing the bottom feed (with open gearbox)
Requirement
With the stitch length set at "0" the bottom feed dog must not carry out any feeding moti-
on when the balance wheel is turned.
● Switch on the machine.
● While continuously turning the balance wheel, adjust reversing crank 1 (screw 2) in ac-
cordance with the requirement.
● Switch off the machine.
1
2
