Adjustment
13
Fig. 1 - 8
1.05.07 Zigzag stitch width
Requirement
At the largest zigzag stitch setting, marking 1 must be at the largest zigzag value on
scale 2.
● Turn the zigzag stitch adjustment lever 3 in accordance with the requirement.
● Move screw 4 upwards until it touches and then tighten it.
If the machine is equipped with a needle plate with a smaller hole than is mar-
ked on the scale, the zigzag limit must be set according to the needle hole
width on the needle plate.
4
1
2
3
