Pfaff 918

Adjustment
29
● Without turning it, adjust the needle bar (screws 1) in accordance with the requirement.
Fig. 1 - 23
1.05.23 Final adjustment of the needle height
Requirement
With the zigzag stitch set at "0", the needle position set at "left" and the hook point in the
middle of the needle, the top edge of the needle eye must be 0.5 mm underneath the
hook point.
1
0,5 mm
