Pfaff 918 Adjustment Manual

Adjustment
11
Fig. 1 - 6
1.05.05 Zero stitch and zigzag stitch scale
Requirement
With the zigzag stitch set at "0":
1. the needle bar must not move laterally when the balancewheel is turned and
2. the marking "0" on scale 1 must be at marking 2.
● Set the needle position adjustment lever 4 to "middle" and loosen screws 5 and 6.
● Run the machine slowly and turn the zigzag stitch adjustment lever 3 to the right until the
needle bar no longer moves laterally.
● Turn the machine off. Move screw 5 to the right until it touches and then tighten it.
● Loosen screws 7 and move scale 1 in accordance with requirement 2.
● Tighten screws 7.
Screw 6 remains loose for the following adjustment.
1
2
3
4
5
6
7
7
