Sewing
4 - 2
2
1
4.02 Sewing with remaining bobbin thread count
The remaining bobbin thread count function is activated, when parameter "660"
is set at value "2". The total number of stitches for the bobbin is entered under
parameter "760". More information about the parameter setting is contained in
Chapter 5.03 Parameter settings.
● If the total number of stitches have been
sewn, the machine stops automatically
with the needle lowered and LED 1
flashes.
● If sewing is continued without a bobbin
change, LED 1 remains lit up
permanently.
● Set the pedal at its neutral position (pedal
position "0").
● Complete the seam (pedal position "+1").
● Carry out the thread trimming function
(pedal position "-2").
The bobbin thread monitor is reset.
● Change the bobbin.
The bobbin thread monitor can be reset at any time by pressing key 2 and at
the same time operating the pedal in position "-2".
Fig. 4 - 02
