Bedienungselemente
2 - 1
Fig. 2 - 01
2 Control elements
2.01 Control device for remaining bobbin thread
Bobbin thread monitor
● When the use of the last amount of
the remaining thread supply begins, the
LED 1 starts flashing.
● When the remaining thread supply has
been used up, the LED 1 lights up
permanently until the bobbin has been
changed.
Bobbin thread counter
● When the thread counter reaches its end,
the LED 1 starts flashing.
● If sewing continues without the bobbin
being changed, the LED 1 remains on
permanently until the bobbin is changed.
To select thread monitoring or
thread counting see Chapter
5.03 Parameter settings.
2.02 Pedal
0 = Neutral position
1 = Sewing
2 = Raise presser foot
3 = Trim sewing threads / reset
bobbin thread monitor or bob
bin thread counter
Fig. 2 - 02
0
+ 1
- 1
- 2
1
