Adjustment
5 - 5
3 382 Average value for switching threshold B 0 – 100 15
bobbin thread monitor
6 660 Bobbin thread monitor A 0 – 2 0
0 = off
1 = bobbin thread monitor on
2 = bobbin thread reverse counter on
7 760 Number of stitches A 0 – 250 5
for remaining thread after reaction of
bobbin thread monitor
(for bobbin thread monitoring)
No. of stitches (x 200)
(for remaining bobbin thread count)
797 Hardware test C ON-OFF OFF
798 User level A 0 – 255 0
0 = operator level A
1 = mechanic level B
11 = service level C
5.03.03 List of parameters
Parameter
The standard values listed in the table are basic settings. When required,
deviations are possible.
Group
Description
Standard value
Adjustment
range
Access level
