Preparation
3 - 1
3 Preparation
All regulations and instructions in this Instruction Manual are to be observed!
Special attention is to be paid to the safety regulations!
All preparation work is only to be carried out by appropriately trained personnel.
Before all preparation work, the machine is to be separated from the electricity
supply by removing the plug from the mains or switching off the On/Off switch!
3.01 Winding the bobbin thread, adjusting the thread tension
81-095
81-094
Fig. 3 - 01
4
-
3
2
1
+
81-096
6
5
1
● Fit empty bobbin 1 onto bobbin winder spindle 2 with the rest thread chamber on the
outside.
● Thread the thread as shown in the above illustration and wind it round the bobbin 1 a few
times in an anti-clockwise direction.
● Switch on the bobbin winder by pressing bobbin winder spindle 2 and lever 3
simultaneously.
