Adjustment
5 - 1
5 Adjustment
5.01 Notes on adjustment
All adjustments in this instruction manual apply to a completely assembled machine and may
only be carried out by suitably trained staff.
Machines covers which are removed for control and adjustment work and then set back in
place again are not mentioned in the text.
5.02 Function control and adjustment of the bobbin thread monitor
Requirement
The value of parameter "382" should correspond to the average value of the top and
bottom threshold value of the thread monitor.
● Insert a full bobbin in the bobbin case and place the bobbin case in the hook.
● Switch on the machine.
● Press the TE/Speed key to call up the parameter input function.
● By pressing the corresponding +/- keys, set parameter "797" at "ON" (displaying the
inputs).
● By pressing the corresponding +/- keys, set parameter "798" at value "1" (selecting the
mechanic level).
No / VAL
No VAL
B 797 ON
TE
No VAL
A 101 ON
TE
No / VAL
No VAL
B 798 1
TE
