Preparation
3 - 2
3.02 Inserting the bobbin case / Adjusting the bobbin thread tension
Fig. 3 - 03
5 cm
1
+
-
● Insert bobbin 1 into the bobbin case 2 as shown in Fig. 3-02.
● Place the bobbin in the bobbin case.
● Pass the thread through the slot under the spring as shown in Fig. 3-03. When the thread
is drawn off, the bobbin must turn in the direction shown by the arrows.
● Adjust the thread tension by turning screw 1.
Fig. 3 - 02
2
1
The bobbin fills up during sewing.
If the machine is only run for bobbin winding (without sewing), a hook
base must be fitted in the hook.
Otherwise a jammed thread may damage the hook!
● The tension of the thread on bobbin 1 can be adjusted with knurled screw 4.
● The bobbin winder stops automatically when bobbin 1 is full.
If the thread is wound unevenly:
● Loosen nut 5.
● Turn thread guide 6 accordingly.
● Tighten nut 5..
