13
A
B
C
Operate your sewing machine
Winding the bobbin from the
second spool pin
Push the second spool pin (8) into its hole.
Slide on a spool cap and place the thread
spool on the spool pin.
Threading
Place the thread into guide A and pull
it through opening B to the right under
hook C. Wind the thread clockwise a few
times around the bobbin.
Winding
Switch on the main switch (1). Hold the
end of thread À rmly and press the the
foot control. The winding action will stop
automatically as soon as the bobbin is full.
Cut the thread, push the bobbin to the left
and remove it.
Don’t forget:
Turn the handwheel release disk (3)
back again. Then turn the handwheel (4)
towards you until it snaps into place.
TIP: If the machine is already threaded, you
can easily wind thread from the second spool
pin without having to unthread the machine.
