21
C
B
A
Operate your sewing machine
Changing the needle
Switch off the main switch.
To remove: Lower the presser foot
and move the needle to its highest
point. Now loosen the needle screw
(24) and pull the needle down.
To insert: The Á
at side A of the
needle must face to the rear. Lower
the presser foot and insert the
needle, pushing it up as far as it
goes. Hold the needle and tighten
the needle screw (24) À rmly.
Setting the needle thread
tension
Set the required needle thread tension
(11) with the help of the mark B.
The normal setting for sewing is 4 to 5.
For free-motion sewing, darning and
buttonhole set the tension between 2 and
3.
Dropping the feed dogs
For certain sewing work, e.g. darning or
free-motion sewing the feed dogs have to
be dropped.
To do this, open the bobbin case/hook
cover and move slide C fully to the right.
Now the feed dogs are dropped.
