Introduction
1 Main switch
2 Connection socket “foot control with
main cord”
3 Handwheel release disk
4 Handwheel
5 Carrying handle
6 Bobbin winder
7 Lid with stitches
8 Extra spool pin
9 Spool pin with spool cap
10 Take-up lever
11 Needle thread tension dial
12 Threading path
13 Thread cutter
14 Sewing lamp (max. 15 watt)
15 Presser foot lifter
Parts of your select™ sewing machine
16 Removable accessory tray
17 Base plate
18 Needle plate
19 Stitch length dial
20 Button for “reverse sewing”
21 Stitch selection
22 Thread guide
23 IDT™ System / Integrated Dual Feed
24 Needle holder with À xing
screw
25 Presser foot holder with presser foot
26 Stitch width dial
27 Needle position dial
