EN – 12
Technical characteristics (cont’d)
Characteristics Unit 2033 C2 2063 C2
Frequency HZ 50 60 50 60
Number of stages 2 2
Nominal rotation speed rpm 1500 1800 1500 1800
Nominal flow rate
m
3
/h
cfm
30
23.3
60
42.4
Flow rate Pneurop method
m
3
/h
cfm
27
18.8
55
38
Partial ultimate pressure
(1)
with A120 oil Torr/mbar/Pa 3.75.10
-4
/ 5.10
-4
/
5.10
-2
Ultimate pressure with gas ballast closed Torr/mbar/Pa 2.25.10
-3
/ 3.10
-3
/
3.10
-1
Maximum pressure in continuous operation
• without oil recovery
• with oil recovery
Torr/mbar/Pa
7.5 / < 10 / 1.10
3
75 / > 100 / 1.10
4
Maximum exhaust relative overpressure bar 0.5
Oil capacity (case) l 3.6 7
Weight (pump + motor)
(2)
kg (lb) 66.5(145.5) 102.5 (226)
Inlet and exhaust end fittings DN 40 ISO-KF
Ambient operating temperature °C min 15 / max 45
Ambient storage temperature °C min 5 / max 65
Corrosive applications:
C2 Series
(1)
Partial ultimate pressure measured according to Pneurop 6602 specifications with A113 oil
charge. It may vary if other oils are used (see page 17).
(2)
These values are for pumps equipped with IE2 European three-phase motors.
Note: The pressure measurements were made with a capacitive diaphragm pressure gauge
measuring a total pressure in the absence of a cold trap. Measurements using a Pirani type
gauge can give different pressure values.
Materials
Materials SD Series C1 Series C2 Series
Valves FPM
Optional valves PAI
Oil sight glass Glass Glass PA
O-rings, lip seals FPM
Rotors Carbon steel
HP, LP valves Abestos free plastic
Stators, central housing, plates Cast iron (without Cu, Zn, Cad)
Oil casing Aluminium
Friction rings Alloy of zinc Graphite
The pumps are made in different materials to address the requirements of all major vacuum
applications.
