Pfeiffer Vacuum Pascal 2033 SD - Plan de Montage Cuve Et Bâti

N – 2
27
28
29
30
31
32
33
25
24
23
11
13
14
15
16
17
18
19
20
21
22
M
12a
1
2
3
4
5
6
7
B
8
10
E
D
38
37
26
34
35
SD Model
A
10a
9
12
C1 Model
C2 model
A B D E M Detailed next pages
Rep. Part
Clamping torque
(DaN.m)
4/9/16
Nut H M8 1.5
Nut H M10 3.0
6
Stud M8-28 ZN10C 1.5
Stud M8-28 SS 1.5
Stud M10-30 3.0
14
Stud M8-20 1.5
Stud M10-25 3.0
19 Screw CHC M10-20 4.5
20
Screw CHC M8-25 1.5
Screw CHC M8-20 1.5
Plan de montage cuve et bâti
Oil casing and central housing assembly drawing
Ölbehälter und Pumpenträger Gesamtplan
