Plan du bloc fonctionnel (avec stator flasqué) (C)
Pumping module drawing (with flanged stator) (C)
Gesamtplan: Funktionsblock mit Stator-Monoblock (C)
Rep. Part
Clamping torque
(N·m)
4 Screw CHC M6 x 30 (s.steel) 9.0
9 Straight fitting M/F 1/4 BSPP 18.0
13 Screw CHC M6 x 10 (s.steel) 9.0
15 Screw CHC M6 x 25 (s.steel) 9.0
41 Screw CHC M5 x 8 (s.steel) 7.0
