N – 18
1
2
5
3
4
1a
Plan ensemble motorisation (M)
Motor assembly drawing (M)
Motor Gesamtplan (M)
Rep. Part
Clamping torque
(N·m)
5 Screw CHc M6 x 40 (s.steel) 9.5
2 Screw Hc M6 x 8.8 (s.steel) 2.5
