S-DRIVE - PROGRAMMING PG DRIVES TECHNOLOGY
SK76745/10
The parameter can be set to On or Off.
7.9 Diagnostic Alarm
The diagnostic alarm will create a pulsed type alarm which will sound the equivalent to the TruCharge diagnostic indicator
The parameter can be set to On or Off.
7.10 Diagnostic Alarm Tone
This parameter sets the tone when the alarm is active. The parameter can be programmed to 0, 1, 2 or 3.
0 - Self Resonating 1 - 2khz 2 - 1kHz 3 - 500hz
The diagnostic alarm will sound a warning signal to alert the user that a diagnostic alarm
pattern is about to be sounded. The signal will be a set of fast beeps lasting two seconds. The
slower diagnostic pattern will then be sounded once.
7.11 Brake Disconnected Alarm
The controller has an output to power an audible reversing alarm. The alarm will sound whenever the controllers sense a break in
the Alarm circuit.
The parameter can be set to On or Off.
7.12 Brake Disconnected Alarm Tone
This parameter sets the tone when the alarm is active. The parameter can be programmed to 0, 1, 2 or 3.
0 - Self Resonating 1 - 2khz 2 - 1kHz 3 - 500hz
7.13 Brake Fault Detect
Sets whether the S-Drive detects a fault in the scooter’s electrical brakes or the connections to them. The parameter can be set to
On or Off.
On Means the S-Drive will detect brake faults.
Off Means the S-Drive will not detect brake faults.
This parameter should only ever be set to off if there are no electrical brakes fitted to the
scooter.
7.14 Brake Light
This parameter can be set to On or Off.
When set to On the S-Drive’s Audible Alarm output (pin 3) will provide a brake light function. The brake light will be illuminated as
soon as the throttle is released and will remain illuminated for approximately 1-2 seconds after the scooter has stopped
completely.
When this parameter is set to Yes then no alarm functions will operate.
For wiring details refer to the illustration in Chapter 2 section 4.9.1.
