PG DRIVES TECHNOLOGY S-DRIVE – WARNING SUMMARY
SK76745/10
2.14 Crimping
Defective or poor quality crimps may affect the warranty of the controller. PGDT accepts no
liability for losses of any kind arising from failure to comply with this condition. Chapter 2 section
3.3.
2.15 Wire Gauge and Types
It is the responsibility of the scooter manufacturer to ensure that all wire gauges are suitable for
the intended application. Chapter 2 section 3.4.
2.16 Battery Connection
The scooter manufacturer must install a suitable circuit breaker to provide protection against
short circuits in the battery wiring, power loom or the controller. Failure to comply with this could
result in a fire hazard. PGDT accepts no liability for losses of any kind arising from failure to
comply with this condition. Chapter 2 section 3.5.
2.17 ISO-Test Resistor Configuration
If a Speed Limit Pot. is fitted in series then an ISO-Test Resistor MUST be fitted to comply with
ISO7176-14 section 6.12.3.3 Chapter 2 section 4.3.
2.18 24V
The scooter manufacturer must install a suitable fuse to protect the scooters wiring. Failure to
comply with this could result in a fire hazard. PGDT accepts no liability for losses of any kind
arising from failure to comply with this condition.
At no time should the current passing through pin 7 of S-Drive Scooter Controller exceed the 5A
current rating. Failure to comply with this could result in a fire hazard. PGDT accepts no liability
for losses of any kind arising from failure to comply with this condition.
This connection should have no external capacitance connected to it, and care should be taken not
exceed the fuse rating if lights or other auxiliary functions are connected. Chapter 2 section 4.6.
2.19 0 Volts
At no time should the current passing through pin 13 of the S-Drive Scooter Controller exceed the
5A current rating. Failure to comply with this could result in a fire hazard. PGDT accepts no
liability for losses of any kind arising from failure to comply with this condition. Chapter 2 section
4.10.
2.20 Inhibit 2 Speed
If the Inhibit Speed is greater than 0 then the controller will not enter an inhibit state. Chapter 2
section 4.11.2.
