PGO BR-500 - Lubrication System Description and Flow

A
Camshaft
B
Cylinder-head plane
C
Cylinder-crankcase plane
D
Water pump impeller
E
Minimum oil pressure sensor
F
Oil filter cartridge
G
To the oil sump
H
By-pass valve
L
Oil pump
M
Net pre-filter
N
Driving shaft
O
Connecting rod
PGO BR-500 ENGINE
P.10-122
Lubrication
