INDEX OF TOPICS
INJECTION 9
Introduction………………………………………………………………….…9-2
Precautions………………………………………………………………….….9-4
Troubleshooting……………………………………………………………..….9-5
Immobilizer and EMS control terminals layout…………………………..…9-6
EMS system layout………………………………………………………….…9-8
Troubleshooting procedures…………………………………………………..9-9
Immobilizer system……………………………………………………………9-
17
Decoder and injection controller power supply circuit………………….….9-29
Diagnostic tester connection circuit…………………………………………..9-
33
Injection indicator circuit……………………………………………………..9-
34
Auto diagnostic system……………………………………………………..…9-
37
Fuel feeding system………………………………………………………... ….9-
38
Revolution sensor………………………………………………………...……9-
62
H.V. coil……………………………………………………………………......9-
65
Ignition timing………………………………………………………………..9-
68
Cooling fluid temperature sensor……………………………………….…..9-
71
Sucked air temperature sensor……………………………………….……..9-
75
Pressure sensor…………………………………………………………....….9-
78
Gas valve position sensor(TPS)……………………………………….……..9-
79
Gas valve position signal reset(TPS reset)…………………………………..9-82
Stepper motor……………………………………………………….….…….9-
84
Electric fan control circuit……………………………………………….…..9-
90
