Transmission gear box removal
Take off the CV joints
Loosen the bolts of rear muffler section, and dismantle muffler
Loosen the bolt of transmission with the chassis, loosen the bolts of reverse gear box bracket
with the engine.
Loosen the socket nut of transmission with engine assembly, take off the complete
transmission away from engine.
Attention- when lock this socket nut back to engine, apply anti-loosen glue(loctite#243) to the
inner thread, and lock torque is 100~120N-m
100~120 N-m
apply loctite #243
Damper
bolt
P.6-4
