- Tighten the flywheel lock nut at the
prescribed torque.
Tightening torque:
Flywheel lock nut: 115 ~125 Nm
- Install the chain guide retain plate tightening
the 3 screws at the prescribed torque.
N.B.: Before tightening the screws,
move the start-up rim in contact with
the crankcase and check that it is
free to rotate in counter-clockwise
direction.
Tightening torque:
Chain guide sliding block retain plate
fastening screws: 3 ~4 Nm
PGO BR-500 ENGINE
P.10-63
Flywheel and Start-up
