4. System Installation and Disassembly
Page 30 of
46
4.4.3.1 Systems without the iXM-RS 150F Achromatic Camera
Table 5 lists the order and how to connect the components in a PAS 280 without an iXM-RS 150F
achromatic camera.
Table 5. PAS 280 System Without iXM-RS 150F Achromatic Camera - Connection Details
Order
P/N
Description
Connects to
1
75011000
PAS Power Cable
Aircraft Power Source (add suitable
connector - see 4.4.2 - Connecting the
System to the Aircraft Power Source for
pinout)
Stabilizer, POWER SOCKET
iX Controller, 28 VDC
2
75036000
Power cable, iX Controller/POS AV
iX Controller, left power port
POS AV PCS, PWR
3
75012000
Power cable, iX
Controller/Cameras
iX Controller, right power ports
iXM-RS 280 (right camera)
4
75012000
Power cable, iX
Controller/Cameras
iX Controller, right power ports
iXM-RS 280 (left camera)
5
73233000
USB cable
iX Controller
iXM-RS 280 (right camera)
6
73233000
USB cable
iX Controller
iXM-RS 280 (left camera)
7
75035000
Ethernet cable
iX Controller
POS AV PCS
8
75014000
(for DSM
400
stabilizer)
Com Cable, iX Controller/POS
AV/DSM 400
iX Controller, COM
POS AV PCS, IO2
DSM 400 Stabilizer, INTERFACE
75088000
(for GSM
4000
stabilizer)
Com cable POS AV to GSM 4000
stabilizer
POS AV PCS, IO2
GSM 4000 Stabilizer, INTERFACE
9
75010000
Trigger cable
iX Controller, IO
iXM-RS 280 (right camera)
10
75015000
Event/MEP cable
POS AV PCS, IO1
iXM-RS 280 (left camera)
11
75007000
Multisync cable
iXM-RS 280 (right camera)
iXM-RS 280 (left camera)
12
75022000
Power, Video DP, USB harness
Operator monitor (power, video, USB ports)
iX Controller Power (left ports); video (HDMI);
USB (USB ports)
13
75021000
Power, Video HDMI, USB harness
Pilot monitor (power, video - includes USB
signal)
iX Controller Power (left ports); video (DP);
USB (USB ports)
14
76000600
Keyboard Dongle (supplied with
Keyboard)
iX Controller
15
-
Antenna cable (supplied with
antenna)
Aircraft Antenna Connector
POS AV PCS, A1
16
-
IMU-POS AV (supplied with POS
AV)
POS AV PCS, IMU
IMU
17
-
Ground cable (not supplied with
system)
POS AV PCS Ground screw
Aircraft Ground
