PHICOMM KE 2P User Manual

P a g e 12 | 49
3 Hardware connections
3.1 Package contents
Please check the package content before the installation of the router:
 1 x AC1300 Dual Band Gigabit Wireless Router KE 2P
 1 x power adapter
 1 x RJ-45 Ethernet cable
 1 x Quick Installation Guide
 1 x GPL license
3.2 Connect your devices
Follow these steps below to connect your devices.
2. Connect the power adapter into an electrical socket, connect the other end to the
router.
P a g e 13 | 49
3. Connect your modem to the WAN port on the router using a RJ-45 cable.
Note
 Make sure your modem has proper Internet connection.
 If you have a wired ethernet connection to Internet instead of a
modem, connect RJ-45 cable directly to the WAN port on the
router, and turn on the router, then continue with the following
instructions to complete the router setup.
4. Connect your device to the router (wired or wireless):
Wired: Connect your PC to the LAN port on the router with a RJ-45 cable.
Wireless:
Turn on WLAN on your wireless device and connect to@PHICOMM_XX
or @PHICOMM_XX_5G.
XX represents the last two digits of router’s MAC address that can be found on the
label at the bottom of your router.

PHICOMM KE 2P Specifications

General

Color	silver
Wi-Fi Speed	1267 megabits per second
Frequency Band	2.4 ghz, 5.0 ghz
Ethernet Standard	10/100/1000
Ethernet Switch	yes
Wireless Standard	ac, n
Gigabit Ethernet Speed	yes
Firewall	none
Data Encryption	yes
Encryption Type	wpa, wpa2-psk
Ports	rj-45
LAN Ports	4
WAN Ports	1

Weight and Dimensions

Height	1.1 inches
Width	7.1 inches
