PHICOMM KE 2P User Manual

P a g e 34 | 49
3. After you have selected the Custom mode, the necessary parameters, including the
Internet/IPTV VID、Tagged/untagged、Priority are required to set by users.
4. Click Save.
5. Connect the set-top box to the corresponding LAN port which is has been prompted
on the picture.
6.11 IPv6
This function allows you to enable IPv6 function and set up the parameters of the router’s
Wide Area Network (WAN) and Local Area Network (LAN).
To enable IPv6, follow these steps below:
1． On Web Management, go to Main menu > Advanced > IPv6 and toggle on IPv6
switch.
2． Select the WAN Connection Type according to your ISP network topology:
 DHCPv6: Connections which use RADVD IPv6 address assignment.
 PPPoEv6: Connections which use PPPoEv6 that requires a username and
password.
P a g e 35 | 49
 Static IPv6: Connections which use static IPv6 address assignment.
 Tunnel 6to4: Connections which use 6to4 address assignment.
3． LAN settings:
 IPv6 Address Assign Type - Users can choose mode: DHCPv6 Server or SLAAC.
 IPv6 Address Prefix - Get the IPv6 address prefix from the ISP.
 LAN IPv6 Address - Display the LAN IPv6 address created by the device.
4． Click Save.
**********************************************************************************************

PHICOMM KE 2P Specifications

General

Color	silver
Wi-Fi Speed	1267 megabits per second
Frequency Band	2.4 ghz, 5.0 ghz
Ethernet Standard	10/100/1000
Ethernet Switch	yes
Wireless Standard	ac, n
Gigabit Ethernet Speed	yes
Firewall	none
Data Encryption	yes
Encryption Type	wpa, wpa2-psk
Ports	rj-45
LAN Ports	4
WAN Ports	1

Weight and Dimensions

Height	1.1 inches
Width	7.1 inches
