Philips 10BDL3051T User Manual

10BDL3051T
31
reset)
1. After 3 seconds, Power LED will become
amber.
2. After the recovery screen show, power LED
will be green.
R/L
LED strips
1. Default is OFF.
2. Only SICP commands can turn ON/OFF and
set colors on side LED strips.
(3) Use the camera
Use the key combination “Menu+ V_Down” to
enter “launch admin mode”.  click “all app”
launch camera app.
3.3.17.6 File manager app
Home page of File Manager app, this page will list
folder and files.
Press ok key at folder or file, it will popup option
dialog.
* Open : open folder or file.
* Select : select folder or file to edit.
Press select item at option dialog, the top of page
will popup action bar.
: cut : copy
: edit : delete
When you press cut or copy, the page will show
paste icon
You can press back key back to the parent directory
Storage path as below:
* Internal : /mnt/sdcard
* Sdcard path : /mnt/external_sd
* Usb path : /mnt/usb_storage

Philips 10BDL3051T Specifications

General

Multi-touch	Yes
Aspect ratio	16:10
Response time	30 ms
Display diagonal	10.1 \
Display brightness	300 cd/m²
Display resolution	1280 x 800 pixels
Display technology	LED
Contrast ratio (typical)	800:1
Display number of colors	262144 colors
Display diagonal (metric)	25.6 cm
Number of simultaneous touchpoints	5
Built-in camera	No
Power supply type	DC
Placement supported	Horizontal/Vertical
USB 2.0 ports quantity	1
Mean time between failures (MTBF)	50000 h
Certification	CB, CE, FCC A, UL
Product color	Black
Glass thickness	0.7 mm
Panel mounting interface	75 x 75 mm
Number of OSD languages	18
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, NOR, POL, POR, RUS, SWE, TUR
RMS rated power	4 W
Number of built-in speakers	2
Cables included	DC, HDMI, USB
Sustainability certificates	RoHS
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Power consumption (standby)	0.5 W
Power consumption (typical)	6 W
Compatible memory cards	MicroSD (TransFlash)

Weight and Dimensions

Depth	29 mm
Width	261 mm
Height	167.2 mm
Weight	710 g
