HUDSON 8
41
8. Remove the shielding as Fig12.
Remove the five screws remarked in red to remove the shielding.
Fig12
9. Remove main board, power board and USB board as Fig13~Fig14
Remove the seven screws remarked in red to remove the main board, power board and USB board.
Fig13
