231E
LCD
55
1. PRODUCT SPECIFICATION (PM)
1.1 Relationship
Model: LM230WF1-TLA3
Customer: Philips Model: 231E1SB
* Monitor No: HWE123
* Monitor ID:
231E1HSB/00
231E1HSB/93
231E1HSB/96
231E1HSB/27
* EAN No.:
CTN UPC/EAN
231E1SB/00
87 12581 49137 6
231E1SB/93
87 12581 49138 3
231E1SB/96
87 12581 49919 8
231E1SB/27
1.2 Product Data (EE)
23” W TFT LCD monitor
Horizontal frequency 30 - 83 KHz
Vertical frequency 56 – 76 Hz
Screen diagonal 23 Inch
Viewing Angle(CR>10)(H/V) 170/160 °
Max. active horizontal picture size 509.18 mm
Max. active vertical picture size 286.21 mm
2. MECHANICAL SPECIFICATION (ME)
2.1.1 Monitor Housing
The front bezel and the back cabinet are based on Innolux OEM tooling and Philips design chin.
2.1.2 VESA mounting holes
Nil
2.1.3 Kensington Slot
The monitor is equipped with a 7 mm x 3 mm slot.
2.2 Tilt of the monitor
Forward -5 q +2/-0
Backward +20 q +0/-2 q
2.3 Dimensions of monitor
The monitor has the following dimensions:
Unit dimension : 547.2mm (W) * 432.8mm (H) * 201.4mm (D)
Packed unit dimension : 596mm (W) *495mm (H) * 134mm (D) for WW
: 596mm (W) *495mm (H) * 134mm (D) for China
Net weight : 4.5 Kg (Including I/F cable 240 g)
Gross weight : 5.56 Kg for WW
: 5.56 Kg for China
3. LCD SPECIFICATION (EE)
3.1 LCD specification
