Philips 231E1HSB/00 - Page 56

231E1
LCD
56
LGD
INL
Panel
LM230WF1-TLA3 INL_MT2330WD01
Resolution
1920(H) X 1080(V) 1920(H) X 1080(V)
Active area(HxV)
509.184 x 286.216 509.184 x 286.216
Outside
dimensions(WxHxD)
533.2 x 312.0 x
16.5 mm
533.2 x 312.0 x
16.5 mm
Pitch(mm)
0.265 x 0.265 0.265 x 0.265
Display surface
Anti-Glare
type
Anti-Glare
type
Color depth 16.7M colors 16.7M colors
Backlight 4CCFL 4CCFL
Viewing angle 170/160 for H/V 170/160 for H/V
Contrast ratio 1000:1(Typ) 1000:1(Typ)
White luminance 300nit(Typ) 300nit(Typ)
Color gamut 75% 75%
Gate IC
GIP GIP
Source IC
Lusem Lusem
Response time 5ms 5ms
4 COSMETICS APPEARANCE (ME)
4.1 GAP definition
The gap between LCD and front bezel must be <= 1.2mm
4.2 Panel Offset
Panel Offset: Panel disposition tolerance inside the front bezel must be <=1.0mm
4.2 Horizontal tilt
Horizontal tilt between front bezel & LCD shall be <= 1.0mm
5. CONNECTORS (FW)
5.1 Video Connection
The monitor is equipped with a 15 pin mini D-SUB connector.
5.2 PIN Assignment
5.2.1 15 pin mini D-Sub connector
The PIN assignment of the 15 pin mini D-SUB connector / cable is as follows:
Pin Symbol Pin Symbol Pin Symbol
1 Red 6 Red GND 11 GND
2 Green/SOG 7 Green GND 12 Bi-directional data
3 Blue 8 Blue GND 13 H sync
4 GND 9 +5V 14 V sync
5 CableDetect 10 Open 15 Data clock
