241P3LY 24” Wide FHD LCD Monitor
2010/11/30 PHILIPS 9 of 33
241P3 LCD 59
General Product Specification
Sync on green video 0.3 Vp-p Negative (Video 0.7 Vp-p Positive)
2). DVI-D Digital
Input signal: Single TMDS link (Three channels: RX0-/+, RX1-/+, RX2-/+)
3). Audio
Input signal: 1000 mVrms
Loudspeaker (Impedance: 5.25 Ohm +/-15%): 1.5W+ 1.5 W (typical) , stereo for
RMS Power
Frequency range: 450Hz - 20KHz
Headphone connection will mute speakers
4). USB PLUG
USB port (1 upstream, 1 downstream), black jack color
TMDS/+5V/DDC/HPD/CEC Signals
(TMDS Signal)
Termination Supply Voltage AV
CC
: 3.3V±5%
Differential Voltage Level: 150mV – 1200mV
Common Mode Voltage : (AV
CC
– 300mV) – (AV
CC
– 37.5mV)
Differential Sensitivity: 150mVp-p
Maximum differential Voltage : 1560mVp-p
(+5V Power)
Power Supply Voltage : 4.7V – 5.3V
Maximum Current Consumption : 50mA
(DDC Signal)
Maximum Capacitance : 50pF
(HPD Signal)
High Voltage Level : 2.4V – 5.0V
Low Voltage Level : 0 – 0.4V
Output Resistance : 1Kȍ±20%
(CEC Signal, not supported by this model)
Input Low Voltage : < 0.8V
Input High Voltage : > 2.0V
Output Low Voltage: 0 – 0.4V
Output High Voltage: 2.5V – 3.6V
Pull-up Resistor: 2.7Kȍ±10%
Leakage Current in standby/off : < 1.8uA
Maximum Capacitance: 100pF
