241P3LY 24” Wide FHD LCD Monitor
2010/11/30 PHILIPS 8 of 33
58 241P3 LCD
General Product Specification
Contrast ratio : 1000:1(Typ.)
White luminance : 300 nit(Typ.)
Color gamut : 70% (Typ.)
Gate IC :
Source IC :
Response time : 5 ms (typ.)
Vertical frequency range : Hz
2.2 Scanning frequencies
Hor. : 30 – 83 K Hz
Ver.: 56 - 76 Hz
Video dot rate: Analog < 205 MHz, EDID: 210 MHz
Digital < 165MHz, EDID: 170 MHz
Power input: 90-264 V AC, 50/60 r 2 Hz
Power consumption:
< 52W(maximum),
< 42W(typ.)
Functions:
(1) D-SUB analog R/G/B separate inputs, H/V sync separated, Composite (H+V)
TTL level, SOG sync
(2) DVI digital Panel Link TMDS inputs
2.3 Ambient temperature: 0
q
C - 40
q
C
3 Electrical characteristics
3.1 Interface signals
1). D-Sub Analog
Input signal: Video, Hsync., Vsync
Video: 0.7 Vp-p, input impedance, 75 ohm @DC
Sync.: Separate sync TTL level , input impedance 10k ohm terminate
Hsync Positive/Negative
Vsync Positive/Negative
Composite sync TTL level, input impedance 10k ohm terminate
(Positive/Negative)
