241P3LY 24” Wide FHD LCD Monitor
2010/11/30 PHILIPS 13 of 33
241P3 LCD 63
General Product Specification
3.3.2 Factory preset modes (12 modes)
z Factory modes and preset modes are defined in the enclosed timing table file
˅ˇ˄ˣˆ˟˲˼˼˺˲˴˵˿˸
ˁ˿
z Video timing mode (internal firmware support) ,
60Hz: 480i/480p/720p/1080i/1080p
50Hz: 576i/576p/720p/1080i/1080p
3.3.3 Software control functions via OSD / control adjustable functions:
Please refer to following Hudson9 OSD definitions, if any deviation, then refer to PVT Exit
sample.
ITEM
1 OSD DEFINITIONS
ˠˆʳˢ˦˗ʳ˕ʳ
˷˸˹˼˼˼ʳ˲ʳ˅˃˄˃˄˃˄
ˊ
Reset -
No: Exit
Yes: Auto adjustment
for displaying timing
mode and recall factory
preset
2 OSD LANGUAGES
ˢ˦˗˲˦˼˺˲ˠˆ˲˅˃˄
˃˄˅˃ˉˁ˿
9 LANGUAGES
3 OSD TREE
ˠˆʳˢ˦˗ʳ˕ʳ
˷˸˹˼˼˼ʳ˲ʳ˅˃˄˃˄˃˄
ˊ
4 POWER ON LOGO
˅ˆ˪˲˄ˌ˅˃˄˃ˋ˃˲˸
ˁ˵
Power On Logo: Power
On Æ Show up Philips
logo 3 seconds
Æ Change to input
signal.
This picture is reference
only. The official drawing
will send out by PM.
5 Audio Selection Stand-alone – On:
Isolate video and audio
control input
Stand-alone – Off:
Integrate video and audio
control input
Mute – On: Turn off audio
Mute – Off: Turn on audio
