Service Modes, Error Codes, and Fault Finding
EN 35Q529.1E LA 5.
Figure 5-16 Example UART log during SWUPG startup (DVD OK).
UªUretail Jan 16 2008 12:03:04 _____> µ
BTM startup
Boot deviceST NAND512W3A
BFFS init
OK
Searching BootLoader.tdfLoad /bffs0/BootLoader.tdf- Done _____> Bootloader startup
Start /bffs0/BootLoader.tdf
JBL (boottime improvement
BootLoader OS_R0.7.2assert Feb 25 2008 12:49:28Searching boot.bat
Execute /bffs2/boot.bat from label [4] _____> Application selection startup (SWUPG on bffs2)
* SR4->USB SW DL boot2
* On error goto 6
* Load /bffs2/Kernel.tdf - ok
* Load /bffs2/RFSBoot2.tdf - ok
* MemFill 0x87fff000 0x1000 0xff
* Signal 30
* Cmd Line
CMD_LINE arguments passed by JBL : console=ttyS0,38400n8 mem=60M kgdb=ttyS1 l
oglevel=3 init=/init ip=none jffs2_gc_delay=0 root=/dev/ram lpj=1196032 rd_sta
rt=0x80500000 rd_size=1568768* Start /bffs2/Kernel.tdf"htv520EU/92 startup script ..."
"Mounting file systems"
Total usertime mount for /proc: 0,000000 [Sec]
Total systemtime mount for /proc: 0,000000 [Sec]
Total usertime mount for /sys: 0,000000 [Sec]
Total systemtime mount for /sys: 0,010000 [Sec]
Total usertime mount for /dev/shm: 0,000000 [Sec]
Total systemtime mount for /dev/shm: 0,000000 [Sec]
Total usertime mount for /dev/pts: 0,000000 [Sec]
Total systemtime mount for /dev/pts: 0,000000 [Sec]
"Loading PNX5100 Image"
"Launching SW Download Application From Boot2" ______> extra information telling which application is started up
checking hotboot: NO
Standby version 40.x.0.0
start_Init clearing m_InitDoneBlunk
Using errlib version 0.9
Errlib 0.9 registered from process 147
3533 - ReferenRW partition: 4
mounting partition 4 to jffs2 file system passed RW partition: 5
mounting partition 5 to jffs2 file system passed
mounted: </dev/mtdblock6>
Mount check passes, 0 iterations
mounted: </dev/mtdblock7>
Mount check passes, 0 iterations
pffsN_OnMounted sets m_InitDoneBlunk to true
InitCehtvData done
ReadCehtvData ConfigVersion: [0.01] OK
ReadCehtvData ProductID: [Q591E] OK
ReadCehtvData OUI: [0000903E] OK
ReadCehtvData HardwareModel: [0203] OK
ReadCehtvData HardwareVersion: [0100] OK
ConvertAscii2Bin started
ConvertAscii2Bin done
ConvertAscii2Bin started
ConvertAscii2Bin done
ReadCehtvData PublicKey: OK
ReadCehtvData done, ConfigOK: TRUE
Could allocate 36701184. _____>The amount of memory free to load the upg into. If upg size >
free memory, upg will not be programmed
redirecting 1 to 20
00 005.151 Startup m_InitDoneBlunk: 1, m_InitDoneMain: 1
00 005.151 /mnt/jffs0/rupg/tvplf/cetv/display found - Layoutcheck OK
00 005.151 Display flash file : Layout version = 8 ; Content version = 17
00 005.151 Display flash file : Project Id = 1 ; Branch Id = 0
00 005.151 version string: DISPT_001.000.008.017
00 005.151 Using screen option 142, name LCD LGD WUF SAA1 42"
00 005.151 MMIO address obtained from pnx5xxx drv = 0x28000000
00 005.151 redirecting 2 to 23
00 005.164 ***GVC: T2 - ceisusb_m.c (951): "usbdevspN_OnDeviceError( DeviceUnk
nownAttachedError, -1 )" notification given
00 005.165 ***GVC: T2 - ceisusb_m.c (951): "usbdevspN_OnDeviceError( DeviceUnk
nownAttachedError, -1 )" notification given
00 005.167 ***GVC: T2 - ceisusb_m.c (951): "usbdevspN_OnDeviceError( DeviceUnk
nownAttachedError, -1 )" notification given
00 005.169 ***GVC: T2 - ceisusb_m.c (951): "usbdevspN_OnDeviceError( DeviceUnk
nownAttachedError, -1 )" notification given
00 005.171 ***GVC: T2 - ceisusb_m.c (817): "usbdevspN_OnPhysicalDeviceConnecte
d( 0 )" notification given...
00 005.310 startr_init
00 005.310 Startup m_InitDoneBlunk: 1, m_InitDoneMain: 1
00 005.413 gfxptr: 2dea0000
00 005.413 malloc 776605704
00 005.413 Starting STi710x device with i2c protocol version v0.5 !
00 005.413 ST TurnOn first attemptS18,0,Q591E_0.39.0.0
00 005.751 Go!!!!!!!
00 005.850 Por: 1
00 005.860 ST start up OKST SW Version: MPEG4.001.000.000.029
00 005.870 ST HW Version: MP4HW.000.000.012.002
00 005.872 Amount of upgs on usb 0
00 005.874 No upg files found!
00 009.182 ***GVC: T2 - ceisusb_m.c (1199): "usbdevspN_OnNewDevice( 0 )" notification given.
00 009.271 ***GVC: T2 - ceisusb_m.c (1408): "usbdevspN_OnDriveMounted( 0 )" notification given
00 009.273 OnDriveMounted : 0
00 009.559 ceapps OnUpgradesChanged : 0
00 009.567 Amount of upgs on usb 20
--------------------------------- Here Application is started up ------------------------------------------------
00 009.772 20 upgs found on USB. Press right to enter the list. _____>Amount of upgs found.
I_17662_002.eps
110608
